GDM.SCADA liner
©
Turf liner®

GDM.SCADA® liner

2 colours 1 texture 2 formats 3 variants
With the turf liner, surface geometries can be set in an exciting dialog with building architectures. Depending on requirements, the joints can be covered with grass or basalt chippings. This allows you to create a meaningful, ecological accent in any case.

Product details

Chamfers & Edges

Micro bevel (≤ 2x2 mm)

proActive features

37 % greenable area, runoff coefficient ψ = 0.2
proDrain 0,2
37 % greenable area, runoff coefficient ψ = 0.2
52 % greenable area, runoff coefficient ψ = 0.20
proDrain 0,2
52 % greenable area, runoff coefficient ψ = 0.20
Composite system in a 4.0 cm grid
proPower
Composite system in a 4.0 cm grid

Product gallery

Colours

Formats

Legende

Accessible by car
Heavy duty for occasional use
Micro bevel (≤ 2x2 mm)
37 % greenable area, runoff coefficient ψ = 0.2
proDrain
proPower proPower

GDM.SCADA liner 1-1 (nativo - unprocessed)

Lawn liner® 35 mm

Gray
Length x Width x Height
40.0 x 10.0 x 12.0 cm
Gap
35.0 mm
Weight
185.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
37 % greenable area, runoff coefficient ψ = 0.2
Composite system in a 4.0 cm grid

GDM.SCADA liner 5-5 (nativo - unprocessed)

Lawn liner® 42 mm

Anthracite
Gray
Length x Width x Height
40.0 x 40.0 x 12.0 cm
Gap
42.0 mm
Piece
1
Weight
182.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
52 % greenable area, runoff coefficient ψ = 0.20
Composite system in a 4.0 cm grid

GDM.SCADA liner 5-5 Mehrsteinsystem (nativo - unprocessed)

Turf liner® 42 mm multi-brick system

Gray
Length x Width x Height
40.0 x 40.0 x 12.0 cm
Gap
42.0 mm
Piece
5
Weight
182.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
52 % greenable area, runoff coefficient ψ = 0.20
Composite system in a 4.0 cm grid

Turf liner® 42 mm multi-brick system

Gray
Length x Width x Height
20.0 x 40.0 x 12.0 cm
Gap
42.0 mm
Piece
2
Weight
182.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
52 % greenable area, runoff coefficient ψ = 0.20
Composite system in a 4.0 cm grid

Turf liner® 42 mm multi-brick system

Gray
Length x Width x Height
40.0 x 20.0 x 12.0 cm
Gap
42.0 mm
Piece
5
Weight
182.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
52 % greenable area, runoff coefficient ψ = 0.20
Composite system in a 4.0 cm grid

Product notes

Particularly high concrete quality thanks to high-strength quartz, granite or basalt aggregates
More product notes

Laying patterns
