GDM.TETRAGO stone
Paving stone

GDM.TETRAGO® stone

3 colours 1 texture 16 formats 2 variants
A wide variety of laying patterns are possible with GDM.TETRAGO stone. Whether classic laying in a stretcher bond and chessboard pattern or diagonally with bishop's mitres. There are no limits to the imagination.

Product details

Chamfers & Edges

Micro bevel (≤ 2x2 mm)
Micro bevel (≤ 2x2 mm)
with concealed spacers/​composite stabilizers
sharp-edged with GDM KS

proActive features

50 % concrete recycling material
proCycle
50 % concrete recycling material
13 % infiltration-capable surface area, runoff coefficient ψ = 0.3
proDrain
13 % infiltration-capable surface area, runoff coefficient ψ = 0.3
5 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain 0,25
5 % infiltration-capable surface area, runoff coefficient ψ = 0.25
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain 0,25
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
10 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain 0,25
10 % infiltration-capable surface area, runoff coefficient ψ = 0.25
3D displacement protection
proPower
3D displacement protection

Product gallery

Colours

Formats

Legende

Accessible by car
Heavy duty for occasional use
Heavy duty for regular or frequent use
Micro bevel (≤ 2x2 mm)
sharp-edged with GDM KS
50 % concrete recycling material
proCycle
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
proDrain
proPower proPower

Multi-brick system type AU (nativo - unprocessed)

Gray
Length x Width x Height
30.0 x 20.0 x 8.0 cm
Piece
8
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Piece
8
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Gray
Length x Width x Height
20.0 x 10.0 x 8.0 cm
Piece
8
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Gray
Length x Width x Height
20.0 x 10.0 x 8.0 cm
Piece
1
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)

Paving stone (nativo - unprocessed)

Basalt anthracite
Gray
Length x Width x Height
30.0 x 30.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
37.5 x 25.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
25.0 x 25.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
40.0 x 20.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
40.0 x 20.0 x 8.0 cm
Gap
8.5 mm
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
30.0 x 20.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Anthracite
Gray
Length x Width x Height
30.0 x 20.0 x 8.0 cm
Gap
8.5 mm
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Gap
6.0 mm
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
5 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Anthracite
Gray
Length x Width x Height
20.0 x 20.0 x 8.0 cm
Gap
8.5 mm
Weight
175.0 kg / m²
Load capacity
Accessible by car
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
24.0 x 16.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
sharp-edged with GDM KS
Properties
-
Gray
Length x Width x Height
24.0 x 16.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
16.0 x 16.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
sharp-edged with GDM KS
Properties
-
Gray
Length x Width x Height
16.0 x 16.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
30.0 x 15.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
20.0 x 10.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
10.0 x 10.0 x 8.0 cm
Gap
-
Weight
175.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
30.0 x 30.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
37.5 x 25.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
25.0 x 25.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
40.0 x 20.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for occasional use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
30.0 x 20.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
30.0 x 20.0 x 10.0 cm
Gap
8.5 mm
Weight
205.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Gray
Length x Width x Height
20.0 x 20.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Gray
Length x Width x Height
20.0 x 20.0 x 10.0 cm
Gap
13.0 mm
Weight
195.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
13 % infiltration-capable surface area, runoff coefficient ψ = 0.3
Gray
Length x Width x Height
20.0 x 20.0 x 10.0 cm
Gap
8.5 mm
Weight
205.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
50 % concrete recycling material
7 % infiltration-capable surface area, runoff coefficient ψ = 0.25
Length x Width x Height
32.0 x 16.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
10 % infiltration-capable surface area, runoff coefficient ψ = 0.25
3D displacement protection
Gray
Length x Width x Height
24.0 x 16.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Length x Width x Height
24.0 x 16.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
10 % infiltration-capable surface area, runoff coefficient ψ = 0.25
3D displacement protection
Gray
Length x Width x Height
16.0 x 16.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-
Length x Width x Height
16.0 x 16.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
10 % infiltration-capable surface area, runoff coefficient ψ = 0.25
3D displacement protection
Gray
Length x Width x Height
20.0 x 10.0 x 10.0 cm
Gap
-
Weight
220.0 kg / m²
Load capacity
Heavy duty for regular or frequent use
Edge
Micro bevel (≤ 2x2 mm)
Properties
-

Product notes

Concrete paving DIN EN 1338 - Quality D I
